MINI SCF CHORUS

Description

Specification

The mini SCF (SUPER CHORUS Flanger & Pitch Modulation) tributes to TC Electronic's Stereo Chorus Flanger, one of the best modulation pedals ever made since 1976. NUX's modern-tech DSP yields a perfect combination of both worlds: analog and digital. To achieve all of the objectives, our engineers had to develop an algorithm that mimics the principles of BBD chips - the key component of Analog Chorus effects. Quality-grade BBD chips in large mass have become incredibly rare, so this method is not practical for making an affordable analog chorus device.

Input Impedance: 1M9

Output Impedance: 10k2

Dynamic Range: 103 dB

DSP Processing: 48KHz / 32-bit

A/D D/A Sampling Rate: 48KHz / 24-bit

Power: 9V DC(Negative tip, Optional ACD-008 adapter)

Current Draw: less than 100mA

Dimensions: 94(L)X51(W)X53(H)mm

Weight: 175g
