Artno: 540081

2 096 € (Ex VAT)

Description

Specification

With the benefit of its dual-purpose housing, the CX 12 can serve as both an FOH and a monitor speaker. This unit‘s hallmarks include extremely high maximum SPL and excellent speech intelligibility. The CX 12‘s high-frequency horn was optimized using the BEM (Boundary Element Method). Its phase response is uniform; its dynamic range astonishingly wide. All this adds up to a high-definition, strikingly transparent audio image with very precise directivity. What‘s more, multiple units are easily clustered. A high-quality PU finish and a front grille with anticorrosive coating provide armor-like protection on the road. The Speakon Pin Assignment switch on the rear panel sets the input signal to 1 +/- or 2 +/-. The CX 12‘s low-profile housing makes it the stage monitor of choice for demanding performers. It comes in left and right versions for symmetrical monitoring arrays. And if you wish set up a powerful two-way active system, we recommend that you pair this enclosure with HK AUDIO CS 118 or CS 218 subwoofers. It achieves the best audio results when paired with a Lab.Gruppen PLM+ power amp with a LAKE controller as well as with a Powersoft X-Series power amp. Applications: Fullrange sound reinforcement, near-field sound reinforcement with high SPL requirements, e.g. as an FOH top unit, front-fill, side-fill or drum-fill top unit and as a monitor on large stages.

- Application : Facade, Stage monitor

- Baseplate width : 35 mm

- Category : Installation and services

- Color : Black

- Connection : 4 x NL4

- Cutaway : Yes

- Dimensions (mm) : 370 x 670 x 325

- Frequency response : 70 Hz - 18 kHz

- Horizontal dispersion in degrees : 75

- Impedance : 8 Ω

- Input sensitivity (1W/1m) : 99 dB

- Insert type : 10 x M10

- Number of channels : 2 channels

- Peak power : 2,000 W

- Peak power, type : RMS

- Power / type : RMS

- Power output : 500 W

- Recommended amps : 750 W

- SPL max : 131 dB

- Speaker diameter : 12"

- Speaker structure : multi-ply birch

- Transport : 3 handles

- Tweeter : 1,4"

- Type : passive speaker

- Vertical dispersion in degrees : 55

- Weight (kg) : 22.80 kg
